Automatic surface grinding machines metal belt grinder double head
| Categories | Casting machine |
|---|---|
| Brand | OBT |
| Model | OBT-2 |
| Update Time | February 3,2023 |
Detail Information
1. Equipment composition
The equipment consists of a frame, a main drive shaft, a driving rubber wheel, a driven wheel, a grinding motor, a locking adjustment device and the like.
2. Equipment structure performance characteristics
2.1. The machine operates in double-station and does not interfere with each other.
2.2. Balanced structure, stable operation, fast and flexible grinding of the remaining pouring feeder of the casting, fast speed.
2.3 The rubber wheel is light in weight, accurate in dynamic balance, and more than one-third of the power-saving start.
|
Model
|
OBT-2
|
|
Belt size
|
2100*50mm
|
|
Belt speed
|
30m/S
|
|
Motor Power
|
3KW
|
Motor speed | 1420r/min |
Dimensions | 1160*1180*1140mm |
Weight | 306kg |
Voltage | 380V |
Rated frequency | 50HZ |
